中島接頭
Features:
- Interlocking connecting system
- Designed and constructed in accordance with JIS standard
Application:
- Fire Fighting system, deck wash and water delivery
- Maximum Operating Pressure : 15.4 bar
- Medium can be seawater and fresh water
- Suitable for both on-shore and off-shore application
| Size | Tail | Material | ØA | ØB | L |
| 1.1/2" x 1.1/2" | Serrated / Ribbed | Brass | 37 | 61.5 | 46.5 |
| 2" x 2" | Serrated / Ribbed | Brass | 52 | 73.5 | 53.5 |
| 2.1/2" x 1.1/2" | Serrated | Brass | 38 | 91.5 | 41 |
| 2.1/2" x 2" | Serrated | Brass | 49 | 91.5 | 53.5 |
| 2.1/2" x 2.1/2" | Serrated / Ribbed | Brass | 63 | 91.5 | 70 |
***Chrome Plating is optional at request.
